grid 100 Flash Mechanical Keyboard
Price Comparison
| Source | Price | Action |
|---|---|---|
 | $169USD | Buy Now |
The zFrontier Grid 100 Flash is a compact, feature-rich numpad designed for keyboard enthusiasts, gamers, and professionals who demand both functionality and customization. This innovative keypad supports QMK/VIA firmware, ensuring seamless integration and extensive programmability. With its wired connectivity and ANSI layout, the Grid 100 Flash is built for reliability and precision. It comes with hot-swappable sockets, allowing users to easily change switches without soldering. The keyboard is perfect for those who seek a high degree of personalization and performance in a compact form factor.
Specifications
| Name | grid 100 Flash |
| Release year | 2023 |
| Switch Options | Silent |
| Profile | Normal Profile |
| Hot Swappable | ✔︎Yes |
| Layout Size | Numpad |
| Layout Standard | ANSI |
| Layout Ergonomics | Normal |
| Knob Support | ✖︎No |
| Display Support | ✖︎No |
| Mac/Win Support | ✖︎No |
| Multi-Media Keys | ✖︎No |
| USB-C | ✔︎Yes |
| USB passthrough | ✖︎No |
| Connection | Wired, Wired Only |
| Polling Rate | - |
| Battery capacity | - |
| Hall Effect Support | ✖︎No |
| QMK Support | ✔︎Yes |
| VIA Support | ✔︎Yes |
| N-Key Rollover | ✖︎No |
| Mount Style | Gasket Mount |
| Screw in Stabilizers | ✖︎No |
| Sound Dampening | ✔︎Yes |
| Backlight | ✔︎RGB |
| Case Colors | Green |
| Case Material | Aluminum |
| Keycaps Material | PBT, ABS |
| Dimensions | - |
| Weight | - |
Description
Essential Features
The Grid 100 Flash stands out in the market due to its unique and versatile features. It includes three different modules: MINI-PRESS, CYCLE-ENCODER, and CYCLE-JOYSTICK, each providing distinct functionalities. The MINI-PRESS module is a 1x2U tiny keyboard with hot-swappable sockets, while the CYCLE-ENCODER is a 2x2U encoder module, and the CYCLE-JOYSTICK is a 2x2U module with a joystick. This modularity allows users to tailor the numpad to their specific needs. Additionally, the keyboard features an ARGB light bar with 20 addressable RGB LEDs, enhancing its aesthetic appeal. The Grid 100 Flash also comes with 10 semi-silent switches and 10 frosted keycaps, ensuring a unique typing experience.
Material and Build
The Grid 100 Flash boasts a robust and elegant design, crafted from high-quality materials. The chassis is made of aluminum, providing durability and a premium feel. The keyboard's layout is ANSI standard, and it features a 5.5° incline for ergonomic comfort. The MINI-PRESS module includes a Rigid-Flex PCB design, which isolates vibrations from the PCB to the keypad chassis, enhancing typing comfort and reducing noise. The use of PORON damping foams within the chassis further minimizes hollowness and enhances the overall build quality.
Personalization Options
The Grid 100 Flash offers extensive personalization options, making it a favorite among keyboard enthusiasts. Users can remap keys and customize the keyboard's functionality using QMK/VIA firmware. The hot-swappable sockets allow for easy switch changes, enabling users to experiment with different switch types without soldering. The ARGB light bar can be customized to display a wide range of colors and effects, adding a personal touch to the keyboard's appearance. Additionally, the Grid 100 Flash supports the Grid 100 configurator software, which provides an intuitive interface for customizing key mappings and lighting effects.
Beyond Basics
Beyond its core features, the Grid 100 Flash includes several additional functionalities that enhance its usability. It features a USB-C port with ESD protection, ensuring reliable and safe connectivity. The keyboard also includes an aluminum Fn button, which doubles as a bootloader button, adding to its versatility. The core PCB connects to the modules via gold-plated connectors, rated for 200 swaps, ensuring durability and longevity. These extra features make the Grid 100 Flash a comprehensive and versatile numpad, suitable for a wide range of applications.
